Technical instructions MPZ v1.1
www.ccei.fr
15
6.4. Multi-function module indicator
The multi-function indicator, present on the front side of the smart controller for piezoelectric switch
MPZ allows its status to be displayed according to the following table:
Status of the indicator Meaning
Switched off No electrical supply.
Regular flash (1 flash every 5 seconds)
Stand-by. Waiting for the switch to be activated,
the 2 output points are off.
Flashing (every second)
In time delay mode, meaning that the time out
is under way. At least one output point is active
and at the end of the time out, return to the initial
position.
Switched on
In non time delay mode, meaning that at least
one output point is active.
