Technical instructions MPZ v1.1
www.ccei.fr
2
1. Packaged content
• 1 modular smart controller MPZ pre-equipped with
– 1 6-point pluggable connector for the connection of the piezoelectric button
– 1 6-point pluggable connector for the connection of the power and 2 dry contact output points
• Technical instructions (this document)
2. Technical features
Power supply From 85 to 265V~ AC/From 7 to 440Hz
Power consumed Maximum of 6W
Overall dimensions
2 DIN modules
90 x 36 x 56 mm
Weight
Only controller: 100g (with unpluggable terminal blocks)
Full box: 280g
Installation
On standard DIN rail (OMEGA rail) in fuse box
Width 2 DIN modules
Protection index IP-10 (To be integrated in a fuse box)
Compatible buttons
Piezoelectric switch
• simple (no lighting)
• with 12VDC monochrome LED lighting
• with 12VDC RGB LED lighting
Output points
2 NON-independent and configurable contact points
Maximum of 250VAC/3A resistive or 30VDC/3A resistive
Mode of operation
Remote control switch or sequencer, a choice of several modes
Time delay or not
Duration of time out
Depending on choice:
deactivated/3s/30s/3min/15min/30min/1h/2h/4h
RGB markers when off Configurable by a choice of 6 modes
