Technical instructions MPZ v1.1
www.ccei.fr
9
Switch
no. 4
Switch
no. 5
Switch
no. 6
RGB mark-
er ("off" in
normal oper-
ating mode)
Signalling the
status of the
output points
(when active)
Confirmation
flash colour (in
programming)
Number of
flashes of the
module indi-
cator (in pro-
gramming)
OFF OFF OFF
Marker deacti-
vated
fixed Red 1
OFF OFF ON
Regular white
flashes
fixed Green 2
OFF ON OFF
Regular white
flashes
flashing Yellow 3
OFF ON ON
Rainbow: per-
manent colour
gradient
flashing Blue 4
ON OFF OFF
White fade out in
a loop
fixed Magenta 5
ON OFF ON
White fade out in
a loop
flashing Cyan 6
