Technical manual Tild v1.0QC
Attention Installer: This guide contains important information about the installa-
tion, operation and safe use of this product. This information should be given to
the owner and/or operator of this equipment after installation.
Attention User: This manual contains important information that will help you in
operating and maintaining this product. Please retain it for future reference.
2. Packing contents
1 product Tild with:
• 1 thermal probe (P/N: SF130004)
• 1 probe holder for 1.5" pipe
• 1 probe holder for 2" pipe
• 2 screws and 2 dowels for wall mounting
• Technical manual (this document)
3. Technical features
Sizes (L x H x D) 8.5" x 8.25" x 4"
Weight 2.6 lbs - 1.2 kg
Installation Inside and outside, vertically on a wall
Power supply 12 VAC or 24VDC (depending model) 50/60 Hz
Power consumed 2.4W @12VAC
Protection Index IP 55
Filtration pump compatibility
All 110V - 240V single speed pumps
(Note: A variable speed pump can be connected,
Tild will only manage the power supply)
277 V AC / 30 VDC max - 20A max
Light compatibility
All 12 VAC CCEI lights (or 24VDC depending
of the Tild version) (Number of maximum lights
depends of the power supply)
12VAC or 24VDC (depending version) / 16A
max (divided between the 2 connectors)
Heater
All heaters equipped with a POOL or SPA selec-
tion mod via dry contact
277VAC / 30 VDC max - 10 A max
Temperature probe
NTC probes
270 VAC / 30 VDC max - 10 A
Bluetooth
Low energy (V4.x)
Conform R&TTE Directive 1999/5/EC
60m range
Wi-Fi 802.11 b/g/n and "dual band" (2.4 Ghz only)
ccei.ca
2
