Installation
Transit bolts, located at the rear of the
appliance, must be removed prior to
using the appliance to prevent damage.
• Remove the back cover from the
machine.
• Loosen the transit bolts (T1, T2, T3 &
T4 in fig. 6) using a suitable spanner
by turning them anti-clockwise and
then remove them.
• Remove the plastic spacers that were
retained by the transit bolts.
• Replace the back cover onto the
machine.
• Cover the bolt holes with the plastic
plugs supplied.
Do not throw the transit bolts or
plastic spacers away. If you need
to move the washing machine after
installation you should rst replace
the transit bolts and spacers.
Do not install your machine on rugs or
similar surfaces.
For your machine to work quietly and
without any vibration, it should be
g. 8
g. 6
g. 10
g. 9g. 7
g. 8
