Unpacking the Washing Machine
• Remove the base, corner protectors and top cover (Figure 1).
Removing the Transit Bolts
• Remove the screws holding the plastic covers to the back of the
washing machine (Figure 2 and 3).
• Loosen and remove the 3 transit bolts (Figure 3).
• Cover the holes with the plastic covers you have just removed (Figure 2).
Do not throw the transit bolts away. If you need to move the washing
machine after installation you should first replace the transit bolts.
fig. 1
fig. 2
fig. 3
fig. 4
