Using Your Hob
Fig.1
On / O
Zones:
1. Front left 2.0kW 175mm
2. Back left 1.4kW 175mm
3. Back right 3.0kW 215mm
4. Front right 1.4kW 175mm
1
2
3
4
Pause
Booster
Special
programmes
Slider control
Zone
indicator *
Timer
Zone timer
indicator
Control panel:
Power key
* NOTE: The zone indicators are for illustration only, the zones are controlled by the “Power keys”.
