- the green LED lights on during 1 second to conrm programming of the code length.
3] Enter A5 to modify the master code:
- the green LED lights on during 1 second,
- enter the new 4 or 5 or 6-digit master code,
- the green LED lights on during 1 second to conrm programming of the new master code.
4] Press B to exit from programming mode:
- the red LED lights off to conrm exit from programming.
The red LED ashes 4 times to indicate a data computing error
Master code or user code: 12369
When changing to 4-digit code: enter 2369
When changing to 6-digit code: enter 012369
It is recommended to program the codes in 6-digits
and then modify the code length.
CHANGING THE MASTER CODE
1] Enter the master code twice (12345 default value master code):
- the red LED lights to conrm entry in programming mode.
2] Press A5:
- the green LED lights on during 1 second,
- enter the new master code (according to the code length set up),
- the green LED lights on during 1 second to conrm programming.
3] Press B to exit from programming mode. The red LED lights off to conrm exit from programming.
ADDING USER CODES
Group 1: from user number 00 to user number 59, relay 1
Group 2: from user number 60 to user number 99, relay 2
1] Enter the master code twice (12345 default master code):
- the red LED lights on to conrm entry in programming mode.
- pour programmer des codes :
MASTER CODE
MASTER CODE
RED LED
LIGHTS ON
2] To add a user code, enter the user number (from 00 to 99):
- If the user number is free, the green LED lights during 1 second enter the 4, 5 or 6-digit code,
- If the user number is already programmed, the red LED ashes 4 times,
- To modify the user code enter a 4, 5 or 6 digit code,
- To cancel the user code enter 000000 or 00000 or 0000 code,
- The green LED lights on duri ng 1 second to conrm programming.
If the user code is already programmed or is identical to the master code, then the red LED
ashes 4 times to indicates a data computing error. Note that the codes 000000 or 00000
or 0000 are strictly used to deleted a user code only.
3] Press B to exit from programming mode. The red LED lights off to conrm exit from programming.
USER CODE LIST
00 25 50 75
01 26 51 76
02 27 52 77
03 28 53 78
04 29 54 79
05 30 55 80
06 31 56 81
07 32 57 82
08 33 58 83
09 34 59 84
10 35 60 85
11 36 61 86
12 37 62 87
13 38 63 88
14 39 64 89
15 40 65 90
16 41 66 91
17 42 67 92
18 43 68 93
19 44 69 94
20 45 70 95
21 46 71 96
22 47 72 97
23 48 73 98
24 49 74 99
SETTING ILLUMINATION AND OUTPUT TIME
1] Enter the master code twice (12345 default value master code):
- the red LED lights on to conrm entry in programming mode
2] Press A0 to program the key-in keypad time and the illumination time:
4 5cdvigroup.com cdvigroup.com
ENEN
DGA
Cast aluminium Digicode
®
Self Contained
DGA
Cast aluminium Digicode
®
Self Contained
INSTALLATION MANUAL INSTALLATION MANUAL
