- the green LED lights during 1 second. Enter the time in 10th of second 10 for 10 seconds up to 99 for 99
seconds the backlighting dims 10 seconds after the last keypress or switches off after entering a valid code,
- enter 00 for a permanent illumination keys. The green LED lights during 1 second.
3] Press A1 to program relay 1 output time (door release time):
- the green LED lights during 1 second,
- for a timed output enter the time in seconds 01 for 1 second up to 99 for 99 seconds,
- enter 00 for a latched output,
- the green LED lights during 1 second to validate the time.
4] Press A2 to program relay 2 output time (door release time):
- the green LED lights during 1 second,
- for a timed output enter the time in seconds – 01 for 1 second up to 99 for 99 seconds,
- enter 00 for a latched output. The green LED lights during 1 second to validate the time.
5] Press B to exit from programming mode:
- the red LED lights to conrm exit from programming.
The red LED ashes 4 times to indicate a data computing error.
RESET MASTER CODE
Short the white and the yellow wires:
- the green LED lights on,
- one beep is emitted,
- wait until the green LED lights off. Separate the two wires,
- the master code is reset to the factory default value 123456 in 6-digit code length, 12345 in 5-digit
code length or 1234 in 4-digit code length.
CHANGING THE CODE BY THE USER
To authorize a user to modify its own User code short the blue and the yellow wires (Separate the two wires
to disable this function).
1] Enter the old user code:
- the relay is activated and the green LED lights on.
2] Enter the 2-digit sub master code (default sub master code A and B):
- the red LED lights on to authorize the modication.
3] Enter the new user code:
- the green LED lights during 1 second to conrm the new user code The red LED lights off.
4] Check the new user code to make sure of the modication.
SETTING A SUB MASTER CODE
The Sub Master code allows the user to change its own code without entering in programming mode. For
security reasons the code need to be changed periodically. This feature makes it easier and faster to change
its code
1] Enter the master code twice (12345 default master code):
- the red LED lights on to conrm entry in programming.
2] Press A7 to program a sub master code for the user individual Pin code modication of Group 1:
- the green LED lights on during 1 second,
- enter the new 2-digit sub master code,
- the green LED lights on during 1 second to conrm programming of the sub master.
3] Press A8 to program a sub master code for the user individual Pin code modication of Group 2:
- the green LED lights on during 1 second,
- enter the new 2-digit sub master code,
- the green LED lights on during 1 second to conrm programming of the sub master.
4] Press B to exit from programming:
- the red LED lights off to conrm exit from programming.
AUDIBLE SIGNAL
The audible signal is enabled in programming mode and when the relay is energised after a valid code.
To enable the audible feedback on a key press:
1] Enter the master code twice (12345 default value master code):
- 2 beeps are emitted to conrm entry in programming mode.
2] Press A twice:
- One beep is emitted,
- Press 0 to disable the audible signal during a keypress,
- Press 1 to enable the audible signal during a keypress,
- One beep conrms the modication.
3] Press B to exit from programming:
- 2 beeps are emitted to conrm exit from programming mode.
6 7cdvigroup.com cdvigroup.com
ENEN
DGA
Cast aluminium Digicode
®
Self Contained
DGA
Cast aluminium Digicode
®
Self Contained
INSTALLATION MANUAL INSTALLATION MANUAL
