Cebora MIG 2035/MD - Page 16

CEBORA S.p.A. 16
3.300.181-A 10-03-2016
GB
Error
code
Error description
Solutions
2
EEPROM error.
Replace Control board.
6
CAN bus communication error
between Wire Feeder and Power
Source, or between Control Panel
and Power Source (detected by
Power Source).
Alarm detected by Control board. Check CAN bus
connection between Control board, Motor Control
board and Panel Control. Make sure compatibility of
the program releases inserted into the boards. Replace
Control and/or Motor Control boards and/or Control
Panel.
“rob
int”
7
CAN bus communication error
between Robot Interface and Control
board (detected by Control board).
Alarm detected by Control board. Check CAN bus
connection between Control board and Robot Interface.
Make sure compatibility of the program releases
inserted into the boards.
Replace Control board and/or Robot Interface.
9
CAN bus error: Control Panel
doesn’t communicate with Control
board (detected by Control Panel).
Alarm detected by Control Panel. Check CAN bus
connection between Control Panel and Control board.
Make sure compatibility of the program releases
inserted into the boards.
Replace Control board and/or Control Panel.
10
Output voltage and output current
null, with start button pressed.
Voltage or current detecting circuits
damaged.
Replace Control and/or Power boards. Replace Power
Transformer and/or Diode Group and/or output
Inductor and/or current Transducer.
14
Control board Microprocessor
supply voltage error.
Check wiring between Control and Flyback boards.
Replace Control and/or Flyback boards.
20
Master module “interlock” signal
missing.
Check terminals 3 and 4 of J6 on Power board are
connected between them.
Replace Power and/or Control boards.
22
Hardware key reading error.
Replace Control board and/or hardware key.
25
EPLD Fault. Primary current
excessive.
Replace Control and/or Power boards. Replace Power
board and/or Power Transformer and/or secondary
Diode Group.
30
Incorrect trimmer set on Control
board.
Perform trimmer adjusting procedure on Control board,
following Power Source Service Manual instructions.
Replace Control board.
41
Connector board disconnected.
Replace Motor Control and/or Connector boards.
42
Encoder error (excessive difference
between set point and measured
speed).
Replace Encoder or Wire Feeder Motor and/or Motor
Control board.
43
Connector board communication
error (serial UART).
Check flat-cable between Connector and Motor Control
boards. Replace Connector and/or Motor Control
boards.
45
Push-pull board not connected.
Check wiring between Push-pull and Motor Control
boards.
Replace Push-pull and/or Motor Control boards.
“trG”
(53)
Start command present at the
overtemperature alarm reset.
Replace Connector and/or Motor Control boards.
