Dust tank
Fig.5.
1. Dust tank
2. Primary lter
3. High-eciency lter
4. Dust tank cover
Charging base
Fig.6.
1. Signal transmission area
2. Charging terminal
3. Charge indicator
4. Cable slot
5. Charging terminal
Mop bracket and cloth
Fig.7.
1. Mop
2. Mop bracket
3. Velcro
4. Tab
2. BEFORE USE
Take the product out of the box and remove all packaging materials.
Make sure all parts and components are included and in good conditions. If any sign of
visible damage is observed, contact immediately with the ocial Technical Support Service of
Cecotec.
3. INSTALLATION
Robot and charging base installation
Fig.8.
Connect the charging base to a power supply and store the remaining cable. It is important to
store the remaining cable at the bottom of the charging base to avoid it from being dragged
and disconnected.
Place the charging base against the wall, leaving the safety distance indicated in the below
picture.
Note: Ensure a space of at least 1 m on both the left and right side of the charging base, and a
space of at least 2 m in front of it.
Fig.9.
Warning: Do not expose the charging base to direct sun light.
Long press the power button for 3 seconds; when the light indicator turns on, place the robot
on the charging base.
Fig.10.
Steady blue light: ON/operating
Oscillating orange light: Charging
Red light blinks: Error
Note:
Take the robot to the charging base if the battery is low. The robot might not turn on if the
battery is very low.
The robot will automatically turn on when placed on the charging base.
The robot cannot be turned o during charging.
Wet & dry and dust tank installation
Note: It is not suggested to use the scrubbing function for the rst-time use.
Open the tank’s blue silicone lid, ll the tank with water carefully so water does not come out
and close it again. Make sure the silicone clip is properly closed to avoid water from pilling.
Fig.11.
Install the tank in the robot following the indicated direction. Make sure the clip is properly
fastened.
Fig.12.
Only for Wet & dry tank installation:
Attach the mop to the bottom part of the mop bracket with the Velcro.
Fig.13.
Manually press the clips on both sides of the Wet & dry tank and push it into its correct
position. You will hear a click when it is properly xed.
Fig.14.
Recommendations:
Do not use the scrubbing function while the robot is unattended.
Remove the mop bracket when the robot is charging or not in use.
If there are carpets in the house, set Restricted Areas to avoid the robot from passing over
them.
Add some drops of cleaning agent (not corrosive) if considered necessary.
To remove the mop bracket, press the release button and pull from it outwards.
