ENGLISH
1. PARTS AND COMPONENTS
The graphics in this manual are schematic representations and may not exactly match the
product.
Fig. 1
1. Back home button
2. Start/Pause button
Back home button
The robot will automatically go to the charging base when you press this button on the robot
or on the remote control.
Indicator light
- Steady orange light: low battery/back home mode.
- Flashing orange light: charging.
- Steady blue light: fully charged/standby mode/cleaning.
- Oscillating red light: error/tank missing.
Power/operation button
1. Hold down this button for a few seconds to turn the robot on or o.
2. Press it to start cleaning too.
Fig. 2
1. Anti-collision sensor
Fig. 3
1. Free-fall sensors
2. Driving wheels
3. Power switch
4. Charging terminals
5. Omnidirectional wheels
6. Side brushes
7. Battery
8. Mixed tank
9. Main brush
Fig. 4
Charging base
