CEL-MAR ADA-401WP - Table of Modbus-Rtu Addresses; Modbus Registers Measuring Channels Readout by Function 04 (3 X - References) Input Registers or Function 03 (4 X - References) Holding Registers

enable easy integration of 1-wire sensors with existing automation systems.
Extended implementation of the MODBUS-RTU protocol is available by contacting the service department.
7.1. TABLE OF MODBUS-RTU ADDRESSES
7.1.1. MODBUS REGISTERS MEASURING CHANNELS READOUT BY FUNCTION 04 (3X –
REFERENCES) INPUT REGISTERS OR FUNCTION 03 (4X – REFERENCES) HOLDING
REGISTERS
Address
3X
(F04)
Address
4X
(F03)
Number of
measuring
channel
Data address
for measuring
channel
Data description Attribute Value
Measurement value for measuring channels
30001 40001 0 0 Measurement value R 16-bit register
30002 40002 1 1 Measurement value R 16-bit register
30003 40003 2 2 Measurement value R 16-bit register
30004 40004 3 3 Measurement value R 16-bit register
30005 40005 4 4 Measurement value R 16-bit register
30006 40006 5 5 Measurement value R 16-bit register
30007 40007 6 6 Measurement value R 16-bit register
30008 40008 7 7 Measurement value R 16-bit register
30009 40009 8 8 Measurement value R 16-bit register
... ... ... ... ... ...
30064 40064 63 63 Measurement value R 16-bit register
Measuring Channel condition
30201 40201 0 200 Channel condition R 16-bit register
30202 40202 1 201 Channel condition R 16-bit register
30203 40203 2 202 Channel condition R 16-bit register
30204 40204 3 203 Channel condition R 16-bit register
30204 40204 4 204 Channel condition R 16-bit register
30206 40206 5 205 Channel condition R 16-bit register
30207 40207 6 206 Channel condition R 16-bit register
30208 40208 7 207 Channel condition R 16-bit register
30209 40209 8 208 Channel condition R 16-bit register
... ... ... ... ... ...
30264 40264 63 263 Channel condition R 16-bit register
Readout the serial number circuit
The serial number is 8-bytes B0, B1 ... B7
30401 40401 0 400 serial number SN-C00-B0-B1 R 16-bit register
30402 40402 0 401 serial number SN-C00-B2-B3 R 16-bit register
30403 40403 0 402 serial number SN-C00-B4-B5 R 16-bit register
30404 40404 0 403 serial number SN-C00-B6-B7 R 16-bit register
30405 40405 1 404 serial number SN-C01-B0-B1 R 16-bit register
30406 40406 1 405 serial number SN-C01-B2-B3 R 16-bit register
30407 40407 1 406 serial number SN-C01-B4-B5 R 16-bit register
30408 40408 1 407 serial number SN-C01-B6-B7 R 16-bit register
... ... ... ... ... ... ...
30653 40653 63 652 serial number SN-C63-B0-B1 R 16-bit register
30654 40654 63 653 serial number SN-C63-B0-B1 R 16-bit register
30655 40655 63 654 serial numberSN-C63-B0-B1 R 16-bit register
