Accuracy and range of measurement
Measurement range of sensors Specified in the instructions of sensors.
Measurement accuracy of sensors
Specified in the instructions of sensors.
Electrical Parameters
Power requirements 10 - 24 – 30 V DC
Power cable
Recommended length of power cable < 3m
Power 3W
Protection from reverse power polarization
YES
Galvanic isolation 3kV DC between power circuit and signal line RS-485
Optoisolation
~ 3kV between 1-WIRE signal line and RS-485
Electromagnetic compatibility
Resistance to disruptions according to the standard PN-EN 55024.
Emission of disruptions according to the standard PN-EN 55022.
Safety requiring According to the PN-EN60950 norm.
Environment
Commercial and light industrial.
Environmental Parameters
Operating temperature -30 ÷ 60°C
Humidity
5 ÷ 95% - non-condensing
Storage temperature -40 ÷ 70 °C
Casing
Dimensions
53 x 90 x 62 mm
Material ABS / PC (self-extinguishing)
Degree of casing protection
IP40
Degree of terminal protection IP20
Weight
0,10 kg
According to standard DIN EN50022, DIN EN43880
Location during work
Free
Mounting method On the rail compliant with DIN35 / TS35 standard.
28
ADA-401WP
Dear Customer,
Thank you for purchasing CEL-MAR Company product.
We hope that the ADA-401WP module and this user manual help simplify your network of 1-Wire sensor for industrial applications.
We also wish to remind you that CEL-MAR Company are a manufacturer of the widest selections of data communications products
in the world in applications such as: data transmission converters in RS232, RS485, RS422, USB, Current Loop, Fibre-Optic and
Ethernet Converters and many others.
We welcome your feedback so please contact us to tell how you like our products and how we can satisfy you present and future
needs.
CEL-MAR sp.j.
Department of IT and Electronics
Sciegiennego 219C, str.
25-116 Kielce, POLAND
Tel : +48 41 362-12-46
Tel/fax : +48 41 361-07-70
Web : http://www.cel-mar.pl
Office : office@cel-mar.pl
Sales department : sales@cel-mar.pl
Technical information : support@cel-mar.pl
