- 16 -
Adjusting the Rollers
Note: all of the component parts of the wheel axle assembly will sink in water;
use care when removing the assembly.
As supplied, the rollers are positioned such that they will accommodate the majority of
Personal Watercraft (PWC’s) on the market. However, it may be necessary to change the
position for use with certain PWC’s where the rollers interfere with the contours of the hull.
Note: The first 3 axles and the front axle are not interchangeable with the middle axles.
The two entry rollers are not changeable and are tighter than the rest of the rollers; do not
remove these rollers unless it is for service replacement, in which case they will need to be
replaced in the same configuration.
The rollers can be reconfigured to one of three positions on each axle and placed into any of
the positions on the
Xpress
port.
Removal of Wheels
To remove a wheel assembly use a lever such as a 2” x 2” piece of wood. Ensure that there
are no sharp parts that may puncture the body of the
Xpress
.
Insert the end under the axle as shown and gently but firmly apply upward pressure until the
whole assembly comes free from the main body.
