CEN-TECH 60431 User Manual

Page 9
For technical questions, please call 1-800-444-3353.
Item 60431
SAFETYOPERATIONMAINTENANCE SPECIFICATIONS
C
harging Battery Installed in Vehicle
A S
P
ARK NEAR BATTER
PARK NEAR BATTERP
Y
ARK NEAR BATTERYARK NEAR BATTER
MA
Y MAY
Y
MAY MA
C
AUSE BATTER
Y
AUSE BATTERYAUSE BATTER
EX
Y EXY
P
LOSION.
TO
REDU
C
E RISK OF
A S
P
ARK NEAR BATTER
PARK NEAR BATTERP
Y
ARK NEAR BATTERYARK NEAR BATTER
FOLLOW THESE INSTRU
Y FOLLOW THESE INSTRUY
C
TIONS EXA
C
TL
Y
TLYTL
.
Y.Y
TO
P
REVENT SERIOUS INJUR
Y
REVENT SERIOUS INJURYREVENT SERIOUS INJUR
:
Wear ANSI-approved splash-resistant safety goggles and heavy-duty rubber work gloves
whenever connecting, disconnecting, or working near battery.
Battery acid can cause permanent blindness.
1.
Position AC and DC cables to reduce risk of
damage by hood, door, or moving engine part.
2.
Stay clear of fan blades, belts, pulleys, and
other parts that can cause injury to persons.
3.
Check polarity of battery posts. POSITIVE
(POS, P, +) battery post usually has larger
diameter than NEGATIVE (NEG, N,–) post.
4.
Determine which post of battery is grounded
(connected) to the chassis. If negative post is
grounded to chassis (as in most vehicles), see 5.
If
positive post is grounded to the chassis, see 6.
5.
For negative-grounded vehicle, connect
POSITIVE (RED) clip from battery charger to
POSITIVE (POS,
P, +) ungrounded post of
battery.
Connect
NEGATIVE (BLACK) clip to vehicle
chassis or engine block away from battery.
Do
not connect clip to carburetor, fuel lines, or
sheet-metal body parts. Connect to a heavy
gauge metal part of the frame or engine block.
6.
For positive-grounded vehicle, connect NEGATIVE
(BLACK) clip from battery charger to NEGATIVE
(NEG, N, –) ungrounded post
of
battery.
Connect POSITIVE (RED) clip to vehicle chassis
or engine block away from battery. Do
not
connect clip to carburetor, fuel lines, or sheet-
metal body parts. Connect to a heavy gauge
metal part of the frame or engine block.
7.
See Table
B on page
8 for
length of charge information.
8.
When disconnecting charger, disconnect
AC
cord,
remove clip from vehicle chassis, and then
remove clip from battery terminal.
9.
After use clean, then store the charger
indoors out of children’s reach.
C
harging Battery Outside Vehicle
A S
P
ARK NEAR BATTER
PARK NEAR BATTERP
Y
ARK NEAR BATTERYARK NEAR BATTER
MA
Y MAY
Y
MAY MA
C
AUSE BATTER
Y
AUSE BATTERYAUSE BATTER
EX
Y EXY
P
LOSION.
TO
REDU
C
E RISK OF
A S
P
ARK NEAR BATTER
PARK NEAR BATTERP
Y
ARK NEAR BATTERYARK NEAR BATTER
FOLLOW THESE INSTRU
Y FOLLOW THESE INSTRUY
C
TIONS EXA
C
TL
Y
TLYTL
.
Y.Y
TO
P
REVENT SERIOUS INJUR
Y
REVENT SERIOUS INJURYREVENT SERIOUS INJUR
:
Wear ANSI-approved splash-resistant safety goggles and heavy-duty rubber work gloves
whenever connecting, disconnecting, or working near battery.
Battery acid can cause permanent blindness.
1.
Check polarity of battery posts. POSITIVE
(POS, P, +) battery post usually has a larger
diameter than NEGATIVE (NEG, N, –) post.
2.
Attach at least a 24-inch-long 6-gauge
(AWG) insulated battery cable to
NEGATIVE (NEG, N, –) battery post.
3.
Connect POSITIVE (RED) charger clip to
POSITIVE (POS, P, +) post of battery.
4.
Position yourself and free end of cable as far away
from battery as possible – then connect NEGATIVE
(BLACK) charger clip to free end of cable.
5.
Do not face battery when making final connection.
6.
See Table
B on page
8 for
length of charge information.
7.
When disconnecting charger, always do
so in reverse sequence of connecting
procedure and break first connection while
as far away from battery as practical.
8.
After use clean, then store the charger
indoors out of children’s reach.
