Page 7For technical questions, please call 1-888-866-5797.Item 67979
Accessory Installation
1. The three accessories include a
magnet, a hook and a mirror (see
Figure B on page 5). All are attached
to the imager head in the same manner.
2. Hold the imager head as
shown in Figure G.
3. Slip the end of the accessory over
the flat sections of the imager
head and then fix the accessory
as shown in Figure H.
Figure G
Figure H
Video-Out Cable Connection
Insert the supplied video-out cable into the video-out port of the
tool, and the other end of the cable into the video-in port of a TV,
the LCD screen will output a high quality real-time image.
