II. Specification
General Specification:
Digital Display: 4 digits LCD display with maximum reading 9999
Symbol and Scale range:
Automatic display according symbols and range input signal.
Polarity:
Displayed when negative signal applied to the input.
Over Load:
is Displayed when input signal exceeds measuring limit.
Sample Rate: 2.5 times/sec
Low Battery Indication:
displayed when the battery is below the required voltage.
Power Source: 1.5V×2.（UM-4 or AAA size）
Battery Life: about 45 hrs. (Alkaline)
Auto Power Off:
The meter will power itself OFF if there is no push button or rotary
switch operation for 30 minutes.
To deactivate this function, press the “HOLD” button and keep it
pressed down. Then power up the clamp.
Clamp opening size: 30mm
Dimension (L x W x H) : 218 x 84 x 30 mm, 8.58 x 3.30 x1.18 inch
Weight: 270g, 9.52
OZ (battery included)
Accessory:
Instruction Manual, Carrying Case, Test lead, 1.5V Battery×2
