Center 232 - Electrical Specification

3
Electrical Specification:
The accuracy specification is defined as
±
(…%reading
＋
…count ) At 23
±
5
℃
,
≦
80 %RH
True RMS for ACV and ACA accuracy are specified from 5% to 100%
of range. accuracy add
±
(1%rdg) on Crest Factor 1.4<CF<3 at full
scale & CF<6 at half scale.
ACA
Range Resolution Accuracy
Overload
Protection
600A 0.1A
50 ~ 60Hz
±
( 1.5%rdg + 5dgts )
60 ~ 500Hz
±
( 2.5%rdg + 5dgts )
1200App
DCA
Range Resolution Accuracy Overload Protection
600A 0.1A
±
( 1.5%rdg + 5dgts ) 1200App
ACV
Range Resolution Accuracy Input Impedance Overload Protection
600V 0.1V
±
( 1.5%rdg + 5dgts )
50 ~ 500Hz
1M
Ω
1200Vpp
DCV
Range Resolution Accuracy Input Impedance Overload Protection
600V 0.1V
±
( 1%rdg + 5dgts ) 1M
Ω
1200Vpp
KW (Auto ranging)
Range Resolution Accuracy
100KW 0.01KW
AC Power
360KW 0.1Kw
±
( 1.5%rdg + 3dgts )(50~60Hz)
±
( 2.5%rdg + 3dgts )(60~500Hz)
100KW 0.01KW
DC Power
360KW 0.1KW
±
( 1.5%rdg + 3dgts )
Ohm
Range Resolution Accuracy Overload Protection
10000
Ω
1
Ω ±
( 1.5%rdg + 3dgts ) 600Vrms
<100
Ω
600Vrms
