Page 16 For technical questions, please call 1-800-444-3353. Item 56101
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY
REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY
THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
Parts Lists and Diagrams
Pump Parts List
Part Description Qty
1 Bolt M12×55 1
2 Spring Washer 12 1
3 Flat Washer 1
4 Drive Pulley 1
5 Oil Seal Circle 1
6 Flange Plate 1
7 O-ring φ85 1
8 Bearing 1
9 Bolt M12×40 6
10 Oil Breather 1
11 Crank Case End Cover 1
12 Flat Key 1
13 Crankshaft 1
14 Bearing 1
15 Gasket 1
16 Crankcase 1
17 Oil Plug 1
18 Gasket 1
19 Oil Sight Glass 1
20 Drain Oil Bolt 1
21 Second Stage
Cylinder Head
1
22 Bolt M12×40 4
23 Spring Washer 12 4
24 Gasket 1
25 Connecting Rod A 1
26 Connecting Rod B 1
27 Bearing Shell 2
28 Spring Washer 10 4
29 Bolt M10×55 2
30 Bushing 1
31 Clip 2
Part Description Qty
32 Pin 1
33 Piston 1
34 Wiper Ring 2
35 Piston Ring 2
36 Gasket 1
37 Valve 1
38 Aluminum Seal 1
39 Bolt M6×25 4
40 Valve Stop Block 4
41 Spring 8
42 Valve Plate 4
43 Nut M6 4
44 Lock Nut 1
45 Elbow 1
46 Taper Sleeve 1
47 Nut 1
48 Brass Tube 1
49 Cylinder Head 1
50 Spring Washer 4
51 Bolt M10×65 4
52 Bolt M8×60 1
53 Spring Washer 10 1
54 Nut 1
55 Elbow 1
56 Bolt M8×35 2
57 Spring Washer 8 2
58 Gasket 1
59 Radiator 1
60 Connector 1
61 First Stage
Cylinder Head
1
62 Bolt M12×40 4
Part Description Qty
63 Spring Washer 12 4
64 Gasket 1
65 Bushing 2
66 Connecting Rod A 1
67 Connecting Rod B 1
68 Spring Washer 10 2
69 Bolt M10×55 2
70 Bushing 1
71 Wiper Ring 2
72 Piston 1
73 Pin 1
74 Clip 2
75 Piston Ring 2
76 Gasket 1
77 Valve 1
78 Aluminum Seal 1
79 Bolt M8×30 4
80 Spring 8
81 Restrictor 4
82 Valve Plate 4
83 Nut M8 4
84 Air Filter Assembly 1
85 Cylinder Head 1
86 Spring Washer 12 4
87 Bolt M12×70 4
88 Spring Washer 8 4
89 Bolt M8×70 4
90 Nut 1
91 Pump Safety Valve 1
92 Elbow 1
93 Taper Sleeve 1
94 Nut 1
SAFETY OPERATION MAINTENANCESETUP
