Page 20 For technical questions, please call 1-800-520-0882. Engine for Item 56101
Part Description Qty
1 Gasket, Cylinder Head
1
2 Cylinder Head Cover
1
3 Cylinder Head Gasket
1
4 Tube, Breather
1
5 Cylinder Head Cover Bolt
1
6 Stud
2
7 Stud
2
8 Pin
2
9 Bolt, Cylinder Head
4
10 Plug, Spark
1
11 Cylinder Head
1
12 Crankcase
1
13 Seal, Oil
1
14 Sensor, Engine Oil
1
15 Fuel Tank Frame
1
16 Plug, Rubber
1
17 Protector, Oil
1
18 Bolt
1
19 Washer, Flat
2
20 Bolt, Drain Plug
2
21 Clip
1
22 Arm, Governor
1
23 Seal, Oil
1
24 Pin
1
25 Bolt
4
26 Bolt
2
27 Washer, Flat
1
28 Bearing
1
29 Cover, Crankcase
1
30 Gasket, Crankcase
1
31 Engine Oil Plug
1
32 Dipstick
1
33 Pin
2
34 Bolt
7
35 Bearing
1
36 Gear Assy, Governor
1
37 Seal, Oil
1
38 Bearing
1
39 Crankshaft Assy.
1
40 Shaft Assy, Balancing
1
41 Ring Set, Oil
1
42 Clip, Piston Pin
2
43 Piston
1
Part Description Qty
44 Pin, Piston
1
45 Rod, Connecting
1
46 Primary Ring
1
47 Secondary Ring
1
48 Camshaft Assy.
1
49 Valve, Exhaust
1
50 Valve, Intake
1
51 Seat, Valve Spring
1
52 Retainer, Exhaust Valve
1
53 Rotator, Valve
1
54 Guide, Seal
1
55 Tappet, Valve
2
56 Valve Lifter
2
57 Lifter Stopper Plate
1
58 Bolt, Valve Adjusting
2
59 Rocker, Valve
2
60 Nut, Valve Adjusting
2
61 Nut, Valve Lock
2
62 Spring, Valve
2
63 Retainer, Valve Spring
1
64 Starter Assy, Recoil
1
65 Bolt
4
66 Shroud
1
67 Shroud, Cylinder Body
1
68 Bolt
1
69 Bolt
5
70 Carburetor Assy.
1
71 Gasket, Air Cleaner
2
72 Gasket, Carburetor
1
73 Carburetor Insulator
1
74 Gasket, Inlet
1
75 Nut
2
76 Cleaner, Air
1
77 Bolt
1
78 Gasket, Muffler
1
79 Pipe, Exhaust
1
80 Nut
3
81 Gasket, Exhaust Outlet
1
82 Nut
2
83 Muffler Assy.
1
84 Secondary Air Intake
Valve Gasket
1
Part Description Qty
85 Secondary Air
Intake Valve
1
86 Bolt
2
87 Tank, Fuel
1
88 Strainer, Fuel
1
89 Cover, Fuel Tank
1
90 Outlet, Fuel Tank Oil
1
91 Clamp
2
92 Fuel Line
1
93 Clip
1
94 Nut
2
95 One Way Valve
1
96 Fuel Steam Hose
1
97 Air Cleaner Hose
1
98 Fuel Vapor Collector
1
99 Bolt
2
100 Vapor Collector Cover
1
101 Clamp
3
102 Nut, Flywheel
1
103 Pulley, Starter
1
104 Impeller
1
105 Flywheel
1
106 Bolt
1
107 Cap, Spark Plug
1
108 Charge Coil
1
109 Bolt
2
110 Coil, Ignition
1
111 Bolt
2
112 Control Assy, Throttle
1
113 Bolt
2
114 Throttle Returning Spring
1
115 Rod, Governor
1
116 Governor Support
1
117 Nut
1
118 Bolt, Governor Support
1
119 Spring, Governor
1
120 Starter Motor
1
121 Bolt
2
122 Relay, Starting
1
123 Bolt
2
124 Switch, Control
1
125 Bolt
2
126 Support 1
127 Bolt 1
Parts List and Diagram
Parts List
SAFETY OPERATION MAINTENANCESETUP
