Page 18 For technical questions, please call 1-800-444-3353. Item 56101
Tank Parts List
Part Description Qty
95 Tank 1
96 Connector 1
97 Pressure Gauge 1
98 Tank Safety Valve 1
99 Unloader Valve 1
100 Throttle Control 1
101 Connector 1
102 Taper Sleeve 2
103 Pipe Nut 2
104 Brass Tube 1
105 Air Outlet 1
106 Engine 1
107 Bolt M10×40 4
108 Nut M10 4
109 Bracket 1
Part Description Qty
110 Bolt M10×50 4
111 Nut M10 4
112 Washer 8 1
113 Bolt M8×20 1
114 Bottom Plate 1
115 Nut M14 1
116 Spring Washer 14 1
117 Bracket 1
118 Threaded Rod 1
119 Bolt M6×20 1
120 Belt Guard Bracket A 1
121 Belt Guard Frame 1
122 Belt 2
123 Driven Pulley 1
124 Key 1
Part Description Qty
125 Bushing 1
126 Spring Washer 8 2
127 Bolt M8×30 2
128 Bolt M6×10 11
129 Belt Guard Cover 1
130 Bolt M6×10 1
131 Belt Guard Bracket B 1
132 Bolt M8×16 4
133 Washer 8 4
134 Bolt M12×45 4
135 Spring Washer 12 4
136 Bolt M12 2
137 Drain Valve 1
