SPECIFICATIONS
Product Applications Designed for 1/2” or 3/4” Floor Panels with interchangeable Spacer
Fastener Sizes Cleat Nails: 1-1/2” to 2” Long / 1/2” Crown Staples: 1” to 2” long
Fastener Gauges Cleat Nails: 16 Gauge / Crown Staples: 15-1/2 Gauge
Recommended Air Pressure 70 PSI to 90 PSI: Do Not Exceed 90 PSI
Air Inlet Size 1/4” - 18 NPT
Magazine Capacity 100 Cleat Nails or 80 Crown Staples (Top Loading)
Accessories 3mm Hex Key Wrench / 4 mm Hex Key Wrench
5mm Ball End Hex Wrench / Bottle with Air Tool Oil
Safety Goggles / Hammer
Spacer for 1/2” Boards
INITIAL TOOL SET UP/
ASSEMBLY
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set up
or use of this product.
Note: For additional information regarding the
parts listed in the following pages, refer
to the Assembly Diagram near the end of
this manual.
Unpacking
When unpacking, make sure that the
item is intact and undamaged. If any parts
are missing or broken, please call Harbor
Freight Tools at 1-800-444-3353 as soon as
possible.
• This air tool may be shipped with a
protective plug covering the air inlet.
Remove this plug before set up.
Air Supply
TO PREVENT
EXPLOSION:
Use only clean, dry, regulated,
compressed air to power this
tool. Do not use oxygen, carbon
dioxide, combustible gases, or
any other bottled gas as a power
source for this tool.
Quick
Coupler
Recommended Air Line Components
Regulator with
Pressure Gauge
Quick
Coupler
Air Hose
on Reel
Valve FilterOiler
Coupler
Plug
Tool
Air
Compressor
Coupler
Plug
1. Incorporate a lter, regulator with
pressure gauge, oiler, in-line shutoff
valve, and quick coupler for best service,
as shown in the diagram above. An in-
line shutoff ball valve is an important
safety device because it controls
the air supply even if the air hose is
ruptured. The shutoff valve should be
a ball valve because it can be closed
quickly.
Note: If an automatic oiler system is not
used, add a few drops of Pneumatic
Tool Oil into the airline connection before
operation. Add a few more drops after
each hour of continual use.
2. Attach an air hose to the compressor’s
air outlet. Connect the air hose to the air
