Page 13For technical questions, please call 1-800-444-3353.SKU 97586
Part Description
1 Cylinder Bushing
2 Plunger
3 O-Ring 19.2×1.8
4 O-Ring 15.9×1.8
5 Poppet
6 O-Ring 42.5×5.4
7 O-Ring 17.5×2.6
8 O-Ring 57.4×3.5
9 Piston Assembly
10 Head Cap
11 Screw M5×16
12 Cylinder Cap
13 Screw M4×20
14 Spring Washer 4
15 Poppet Actuator
16 O-Ring 54.2×3.5
17 Seal
18 Body
19 Bumper
20 Nose
21 Screw M3×18
22 Spring Pin 3×14
23 Bafe Plate
Part Description
24 Screw M5×16
25 Spring Washer 5
26 Blade Guide
27 Limited Nail Plate
28 Shoe
29 Joint Guider
30 Bushing
31 Screw M6×16
32 Spacer for 3/4” Boards
33 Screw M6×12
34 Spring Pin 3×20
35 Fixed Magazine
36 Spring Washer 6
37 Screw M6×35
38 Feeder Shoe
39 Spring
40 Bafe Lock
41 Screw
42 Magazine Plate
43 Spring
44 Latch
45 Washer 3
46 Screw M3×5
Part Description
47 Spring Washer 3
48 Leaf Spring
49 Screw M3×8
50 Movable Magazine
51 Spring Pin 2.5×11
52 Nut
53 Washer
54 Clamp Screw
55 Air Plug
56 Arm
57 Hammer
58 Spacer for 1/2” Boards
60 Screw M3×6
61 Magnet
62 Rail
63 Screw M4×16
64 Limited Plate
65 Nut M4
66 Spring Washer 4
67 Bushing
68 Spring Pin 3×12
69 Washer 4
70 Hook
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY
CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
REV 10g
