Page 14 For technical questions, please call 1-800-444-3353. Item 98895
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description Qty
1 Trigger 1
2 Trigger Bolt 1
3 Outer Housing 1
4 Casing 1
5 Valve Core 1
7 Seal Ring 2
8 Seal Ring 1
9 Valve Needle 1
10 Spring 1
11 Bolt 1
12 Control Valve 1
13 Screw 2
14 Washer 1
15 Bearing 6000 1
16 Rear Plate 1
17 Rear Spacer 1
18 Cylinder 1
18-1 Spring Pin 3
19 Rotor 1
20 Vane 5
21 Bolt 3
22 O-Ring 1
23 Front Plate 1
24 Bearing 6000 1
Part Description Qty
25 Front Spacer 1
26 Spindle 1
27 Shaft Key 1
28 Backing Pad Retainer 1
29 Bearing 6001 1
30 Bearing 6001 1
31 Felt Ring 1
32 Cover 1
33 Clip Ring 1
34 Washer 1
35 Exhaust/Dust Collection Port 1
36 Base Ring 1
37 Flexible Rubber Cover 1
38 Set Screw 4
39 Wrench 1
40 Hex Screw 4
41 Backing Pad 1
42 Air Regulator 1
43 Seal Ring 1
44 Air Regulator Knob 1
45 O-Ring 1
46 Dust Collection Hose 1
47 Dust Bag 1
To Next Page
