Centurion D2 Turbo - Automatic Closing (Autoclose Mode)

1. Identification of parts
Refer to the drawings below, for how to identify your D2 Turbo operator
and its parts.
1. Motor fuse
2. Motor enclosure
unit
3. Camlock cover
4. Manual release
thumbwheel
5. Foundation plate
6. Spare fuse
7. Function Dial
8. Status LED
9. Pushbutton
10. D2 Turbo
controller
11. Settings Dial
12. 12V 7.2Ah or
5Ah battery
13. Battery strap
14. Pulley guard
15. Gate mounted
origin marker
16. Origin marker
bracket
17. D2 Turbo
controller
18. 12V 7.2Ah or
5Ah battery
19. Motor housing
20. Pinion
21. Pinion guard
Identification
of
parts
2
4
3
5
6
13
15
14
16
17
18
19
20
21
FIGURE 1
1
page 3
