Centurion SD04 - Programming remote controls; Entering Learn mode; Operating Functions

page 50
www.centsys.com
The SDO4oerssevenmenulevelspertainingtosixdierentfunctionsthatcanbe 
activated either via a handheld remote control or via the four-button wireless wall
switch.Eachmenulevelandfunctionhasadierenteectuponthecontrollerand
the load which it controls. In addition, a seventh menu can be accessed which will learn
the buttons of a four-button remote control or wall switch in the order described below.
9.1. Entering ‘Learn’ mode
9.1.1. Using the Learn button
MomentarilypresstheLearnbutton.TheLEDDisplaywilldisplay“00”
1
toconrmthat
theuserisintheprogrammingmenu.Scrollusingthe‘+’and‘-’buttonstochoose
desired function. When desired function is selected, press and hold transmitter button
forapproximately5seconds.TheCourtesylightwillstopashingtoindicateavalidRF
signal. The remote is now learned into the system. The number of beeps indicates the
function that has been learned.
9.1.2. Using a Remote Transmitter.
Onlytransmitterbuttonslearnedinto“LightFunction/RemoteLearning”caninitiate
remote learning. Press and hold transmitter button for approximately 5 seconds.
Thecourtesylightwillashandthedisplaywillshow‘ru’.Scrollusingthe‘+’and‘-’
buttons to choose the desired function. When the desired function is selected, press and
holdthetransmitterbutton.TheCourtesylightwillstopashingtoindicateavalidRF
signal. The remote is now learned into the system. The number of beeps indicates the
function that has been learned.
Any button can be set to control the Trigger, Courtesy light, Holiday Lockout,
Autoclose Override, Open Only, or Close Only features.
1.Withanemptymemory,‘00’willbedisplayed,otherwiseitwilldisplaythenumberofremoteslearnedintothesystem.
9.2. Operating Functions
9.2.1. Run Function - Open / Stop / Close
This function is associated with opening, stopping and closing the door only.
Operation
Momentarily press the associated remote control button to open, stop or close the door.
If the door is busy closing, pressing the remote control button will cause the door to
stop and a second press will reverse its direction of travel and start opening.
If, on the other hand, the door is busy opening, pressing the remote control button will
cause the door to stop. Pressing the remote control button a second time will cause the
door to reverse its direction of travel and start closing.
Learning procedure
EnterLearnmode,(Refer9.1).Usingthe‘+’and‘-’buttons,select‘ru’.Pressandhold
thetransmitterbuttonuntilthedisplayashes“ru”andthebuzzerbeepsonce.
The system will remain in this learn mode for 10 seconds after the last
remote or wall transmitter button has been learned and automatically exit after
this time. A function can be learned to any button, provided that the button has
not yet been learned to another function.
9. Programming remote controls
SECTION 9
PROGRAMMING REMOTE CONTROLS
