SPECIFICATIONS SECTION 2
2.2. Technical specications
T10 T12
Input voltage 230V AC @ 50/60Hz
1
Motor voltage 24V DC
Motor power - rated 80W DC 100W DC
Motor supply
Battery supply 2 x 3.4 Ah
24 V DC
Battery supply 2 x 3.4 Ah
24 V DC
Max door width 6500mm
Max door area 10m² 15m²
Max lifting capacity 1000N 1200N
Operations in standby
mode
12 to 30 depending on the
door size / weight / height
/ duration of power failure
/ condition of batteries
12 to 30 depending on the
door size / weight / height
/ duration of power failure
/ condition of batteries
Operator travel speed
Tip-up: 80mm/sec.
Sectional: 140mm/sec
with fully charged batteries.
Doortraveladjustment Physical Endstops (Automatic limit set)
Safety obstruction force
system
Built-in menu
Light LED 2W
Autoclose
2
Menu Selectable
Infrared safety beams
Menu Selectable.
(Optional, but recommended)
Radio receiver Code-hopping 433MHz
Receiver code storage
capacity
20 transmitters (consisting of four buttons each)
1:Canoperateoasolarsupply,pleaseconsultCenturionSystems(Pty)Ltdforassistance
2:Requiresinfraredsafetybeamstobetted
TABLE 1
TABLE 2
2.3. Fuse protection
The following protection fuses are provided on the system:
Item Type Rating
Main controller
Motor circuit ATO 15A
