Centurion SD04 - Safety Beams (Sb); Autoclose (ac)

page 55
www.centsys.com
10.2. Autoclose (ac)
• Autoclose can enhance the security of your property by ensuring that your garage
door is never unintentionally left open
• Autoclose will automatically close the garage door from any open position based on
the time set and whether Safety Beams have been triggered
10.1. Safety Beams (Sb)
The installation of safety beams greatly enhances safety by constantly monitoring for
personsorobjectswhichmaypasswithinthepathofthemovinggaragedoor.
Safety Beam Menu (Sb) has the following settings:
• OFF - Safety Beams are disabled
• ON - While closing, the door will stop and re-open if the Safety Beams are triggered
• 2d - While closing, the door will stop and re-open if the Safety Beams are triggered.
While the door is opening, the door will stop and retract 30mm
10.3. Back Jump (bj)
• Backjumpwillreversetheclosedgaragedoorbyanincrementalamount(1-5mm)
inordertoreducemotorgearlock-upandensureeortlessdisengagementinthe
event of power outage
10.4. Motor Supply
• The SDO4 is a battery-driven appliance.
• In the event of a power outage, the batteries can provide up to 30 cycles of operation
10.4.1. Mains Fail Warning
• In the event of a power outage, the Buzzer will beep twice every 30 seconds while
the operator is moving
Autoclose Time Setting Safety Beams Triggered
Safety Beams NOT
Triggered
05 5 seconds 30 seconds
15 15 seconds 90 seconds
30 30 seconds 180 seconds
Autoclosewillonlyfunctionwhenusedinconjunctionwithsafetybeams.
Batterieswillsuerpermanentdamageifnotchargedwithinathreemonth
period while remaining connected to the controller.
SDO4 FEATURES SECTION 10
TABLE 5
