14
1
st
set of attributes
Key pressed
to toggle
attribute
KP-126Pz / KP-164Pz (LED keypads) KP16LCD / KP16LCDL (LCD keypads)
Zone
LED
ON OFF
1
st
line message
2
nd
line message
Enabled Disabled
[1] 1
* “audible” alarm
(with siren activating)
“silent alarm”
(without siren activating)
Alarm Zxx Audible k1 Silent k1
[2] 2 * “steady” siren “pulsing” siren Siren Zxx Steady k2 Pulsing k2
[3] 3
allow manual bypassing disable manual bypassing Bypassing Zxx Enable k3 Disable k3
allow “auto shutdown”
doesn’t allow “auto shutdown” AutoShutdown Zxx Enable k4 Disable k4
[5] 5 enables “forced arming”
doesn’t enable “forced arming” Force Arming Zxx Allowed k5 Not allowed k5
[6] 6 Activate “chime” Don’t activate “chime” Activ.Chime Zxx Enable k6 Disable k6
[7] 7 enabled stay (interior zone)
disabled stay (perimeter zone) Stay Zxx Enable k7 Disable k7
[8] 8 Fast detection (50ms)
Slow detection (300ms) Zone speed Zxx Fast k8 Slow k8
All the first set of attributes is presented below:
Attribute 1:
The alarm triggered by a zone with this attribute established as “audible” will occur with siren activating for a time lapse set in section [038].
The alarm triggered by a zone with this attribute established as “silent” will occur without siren activating.
Note: By default the alarm attribute is set as “audible” for all 1 to 12/16 zones.
Attribute 2:
This attribute is referring to the siren-activating mode – “steady” or “pulsing” and for a same zone the set value of this attribute does mater only if the previous
attribute was set as “audible”.
The alarm triggered by a zone with this attribute established as “steady siren” type will activate the siren in a continuously mode for a time lapse set in section [038].
The alarm triggered by a zone with this attribute established as “pulsing siren” will activate the siren in a pulsing mode (3 seconds ON alternating with 1 second OFF) for
same time lapse set in section [038].
Note: By default the siren-activating attribute is set as “steady” for all 1 to 12/16 zones.
Attribute 3:
When a zone allows manually bypassing it will allow to be bypassed by one of the commands: [*][3][User code] or [BYPASS][User Code].
Note: By default this attribute is enabled for all 1 to 12/16 zones.
Attribute 4:
During the same armed period (or during the same disarming period for 24h zones) the control panel will automatically bypass (“from swinger”) any zone which allows auto-
shutdown and after the zone initiate a number of consecutive alarms equal with “swinger shutdown counter”. After that the zone will no longer generate an alarm. After the
control panel has bypassed a zone “from swinger”, it will report an event code to the central station, if it is programmed within 55 and 66 sections.
This feature is a function of the zone restores option (see [032] section). During the same armed period (or during the same disarming period for 24h zones) the zone will be
bypassed “from swinger” only:
After the siren has cut-off consecutive times, for a number equal with “swinger shutdown counter”, if zone restore event is set to occur upon bell cut-off;
After the zone has violated and closed back for a number equal with “swinger shutdown counter”, if zone restore event is set to occur upon zone closure.
Thus, during the same armed period (or during the same disarming period for 24h zones), a zone which allows “auto shutdown” will trigger:
A maximum alarm number equal with “swinger shutdown counter” established in [041] section, if zone restore event is set to occur upon zone closure;
