Cerber C816 - Page 17

17
[2] 2
Zone assigned to partition B Zone not assigned to partition B
Assig.part.B Zxx Enable k2 Disable k2
After the ATTRIBUTES
3
set for selected zone was established to the required values, press [#] key to confirm.
After [#] key was pressed, the keypad buzzer will sound 6 confirmation beeps and the panel will go back within “main programming menu”.
To exit the main programming menu, press [#] key again.
As for the possible values accepted for the zone attributes with respect to the zone type, the panel rules are:
ATTRIBUTES
1
set ATTRIBUTES
2
set ATTRIBUTES
3
set
ZONE TYPES
Audible /
silent
alarm
Steady /
pulsing
siren
Manually
Bypassing
Auto
Shutdown
Forced
Arming
Activate
chime
Stay
Attribute
Fast/Slow
detection
Intellizone
Sensor under
test
Contacts Type
(NC\NO)
Tamper
Recognition
EOL
Zo
ne Doubling
(ATZ)
ATZ parallel
wiring
Assigned to
partition A
Assigned to
partition B
[00] Not used 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
[01] Delayed1 √ √ √ √ √ √ √ √ 0 0 √ √ √ √ √ √ √
[02] Delayed2 √ √ √ √ √ √ √ √ 0 0 √ √ √ √ √ √ √
[03] Follower √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
[04] Instant √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
[05] 24h burglary
√
√
√
√
0
0
0
√
√
√
√
√
√
√
√
√
√
[10] Tamper √ √ √ √ 0 0 0 √ √ √ √ 0
√ ATZ=0
√ √ √ √
0 ATZ=1
[11] Panic √ √ √ √ 0 0 0 √ √ √ √ √ √ √ √ √ √
[12] Fire 1 0 √ √ 0 0 0 √ √ √ √ √ √ √ √ √ √
[13] Medical Emergency
√
√
√
√
0 0 0
√
√
√
√
√
√
√
√
√
√
[14] Keyswitch / panic √ √ 0 √ √ 0 0 √ 0 0 √ 0
√ ATZ=0
√ √ √ √
0 ATZ=1
[15] StayKeyswitch / panic √ √ 0 √ √ 0 0 √ 0 0 √ 0
√ ATZ=0
√ √ √ √
0 ATZ=1
[16] Guardian round √ 1 √ 0 1 0 0 √ 0 0 √ 0
√
ATZ=0
√ √ 1 1
0 ATZ=1
Legend: - [0] value means that a forced to “0” operation is performed and the attribute cannot be modified;
- [1] value means that a forced to “1” operation is performed and the attribute cannot be modified;
- [√] value means that no forced operation is performed and the attribute can be modified;
- [*] value means that the appropriate attribute is forced to same programmed value of the correspondent attribute of 1 to 6/8 zones and it cannot be modified.
Wiring attributes for high zones number, from 7/9 to 12/16, depending of ATZ on corresponding low zones:
ATZ=0 ATZ=1
ATZ don’t
care
