18
ZONE TYPES
Contacts Type
(NC\NO)
Tamper
Recognition
EOL
Contacts Type
(NC\NO)
Tamper
Recognition
EOL
Zone Doubling
(ATZ)
ATZ parallel
wiring
[00] Not used 0 0 0 0 0 0 0 0
* *
[02] Delayed2 √ √ √ *
* *
0 0
[03] Follower √ √ √ *
* *
0 0
[04] Instant √ √ √ *
* *
0 0
[05] 24h burglary √ √ √ *
* *
0 0
0
0 0
[11] Panic √ √ √
* * *
0 0
[12] Fire √ √ √
* * *
0 0
[13] Medical Emergency √ √ √
* * *
0 0
[14] Keyswitch / panic √ 0 √
* * *
0 0
[15] StayKeyswitch / panic √ 0 √
* * *
0 0
[16] Guardian round √ 0 √
* * *
0 0
NOTES:
1. For some zone types only the default value of some attributes are allowed;
2. “0” = for that zone type the default value for respective attribute is allowed only disabled status (is allowed only the OFF status of corresponding LED - see zone ATTRIBUTE
1
and ATTRIBUTE
2
sets). That means: once the 2-digit group corresponding to some zone type was entered, if one try to put respective attribute in the enabled status (is pressing the
corresponding key to turn ON the corresponding LED), then the keypad buzzer will sound a long error beep and the panel will reject the command.
3. “1” = for that zone type the default value for respective attribute is allowed only enabled status (is allowed only the ON status of corresponding LED - see zone ATTRIBUTE
1
and ATTRIBUTE
2
sets). That means: once the 2-digit group standing for some zone type was entered, if one try to put respective attribute in the disabled status (is pressing the
corresponding key to turn OFF the corresponding LED), then the keypad buzzer will sound a long error beep and the panel will reject the command.
4. “√ “ = the value set by programming for respective attribute is available for corresponding zone type
Remarks:
1. A “fire” zone will trigger only the “audible” alarm, with “pulsing siren”.
2. No attributes could be set as active for an unused zone.
3. The “stay” and “chime” attributes could not be set as active for zone type of: “24h burglary”, “fire”, “tamper”, “panic”, “medical emergency” and “keyswitch/panic”.
4. The “intellizone” could not be set as active for zone type of: “entry delayed 1”, “entry delayed 2” and “keyswitch/panic”.
Section [001] – Definitions for zone 1
While the system is being within “main programming menu”, select section [001] to program parameters of zone 1, then enter the following sequence:
|__|__|[ATTRIBUTES
1
][#][ATTRIBUTES
2
][#][ATTRIBUTES
3
]|#|
where [__][__] is 2-digit group for type and ATTRIBUTES
1
, ATTRIBUTES
2
and ATTRIBUTES
3
are 1, 2 and 3 attribute sets of zone 1.
See defining the 1 to 12/16 zones described in the previous paragraphs.
After entering the 2 digits for zone 1 type, the keypad buzzer will sound 3 beeps and ATTRIBUTES
1
set is displayed. Press [1] to [8] keys and the related
attributes will be activated/deactivated.
