Cerwin-Vega CVE-10 User Manual

CERWIN-VEGA PROFESSIONAL
13
Application #2 – Connecting a second CVE-10, CVE-12, or CVE-15 using MIXED
OUTPUT
A second CVE-10, CVE-12, or CVE-15 loudspeaker can be added using a standard balanced XLR cable as shown in the
example below. A two-speaker system can cover a wider audience and situations where more volume is needed. To add
a second CVE-10, CVE-12, or CVE-15 loudspeaker, connect the MIXED OUTPUT of the first speaker to CH 1 INPUT or CH 2
INPUT of the second speaker. Then, adjust the LEVEL to an appropriate setting on the first speaker. Be sure to adjust the
LEVEL knobs on both speakers to similar settings since the LEVEL knob on the first speaker will not change the volume on
the second speaker.
or
or
or

Cerwin-Vega CVE-10 Specifications

General

Speaker type	-
Speaker position	Front
Speaker placement	Floor
Audio output channels	- channels
Number of woofer drivers	1
Woofer diameter (imperial)	10 \
Amplifier class	D
Product color	Black
Frequency range	50 - 23000 Hz
RMS rated power	1000 W
XLR in	Yes
Connectivity technology	Wired & Wireless
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	286 mm
Width	330 mm
Height	559 mm
Weight	13150 g
