CESAB S212 - 10.7 Drive motor tightening torques

© Cesab 10 – 9 T Code(s): 841, 842, 843
Repair manual: Electric drive motor 1700 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
10.7 Drive motor tightening torques
The drive motor tightening torques are depicted in the figure below:
T30
T30
Nm
3.5
10 mm
10,5
4,5
+ 0,5
Nm
+ 1,5
Nm
