128
MAINTENANCE
Front gear case oil change
4. Place the vehicle on a level surface.
5. Place an oil pan under the gear case to collect the used oil.
6. Remove the oil drain bolt
2
at the bottom of the gear case and
drain the oil.
7. Install the oil drain bolt and tighten it to 18.4 ft-lb. (25 N•m).
8. Remove the oil ller bolt. Add sucient oil to raise the level up
to the brim of the hole.
9. Install the oil ller bolt and tighten it to 18.4 ft-lb. (25 N•m).
NOTE:
Approximate front gear case oil capacity: 11.2 oz. (330mL)
2
