138
MAINTENANCE
Exhaust spark arrestor
Clean carbon deposits from the spark arrester periodically while
the muer and exhaust are at normal air temperature.
CAUTION
Ensure that the exhaust pipe and muffler are fully cooled down
before servicing the spark arrestor.
1. Remove the fasteners
1
.
2. Tap the tailpipe lightly to loosen it and remove the spark
arrester
2
from the muer.
3. Use a wire brush to remove any carbon deposits from the
spark arrester portion of the tailpipe
3
.
4. Insert the tailpipe into the muer and align the bolt holes.
5. Install and torque the fasteners to 7.3 ft-lb. (10 N•m)
1
2
3
