1. Overhaul Information
Front Wheel
Item Standard Service Limit
Vertical 1.0mm 2.0mm
Play of wheel rim
Horizontal 1.0mm 2.0mm
Groove -- 3.0mm
Front
Wheel
Tire
Pressure 35kpa(0.35kgf/cm
3
) --
Rear Wheel
Item Standard Service Limit
Vertical 1.0mm 2.0mm
Play of wheel rim
Horizontal 1.0mm 2.0mm
Groove -- 3.0mm
Rear
wheel
Tire
Pressure 35kpa(0.35kgf/cm
3
) --
Brake System
Item Standard Service Limit
Brake lever play 0mm --
Front brake
Brake disc thickness 3.5mm 4mm
Brake lever play 5-10mm --
Brake Pedal Play 0mm
Rear brake
Brake disc thickness 7.5mm 6.5mm
Battery、Charging System
Item Standard
Model Permanent magnet AC type
Output 3- phase AC
AC magneto Motor
Charging coil Resistance (20℃)
0.2-0.3Ω
Rectifier
Three-phase annular rectification, Silicon controlled
parallel-connected regulated voltage
Capacity 12V18Ah
Fully charged 12.8V Terminal
point
voltage
Insufficient charge <11.8V
Standard 0.9A/5~10H
Battery
Charging
current/time
Quick 4A/1H
Ignition system
Item Standard
Ignition CDI ignition
Type DPR7EA-9(NGK)
Optional DR8EA, D7RTC
Spark Plug
Spark plug gap 0.8-0.9mm
Ignition timing Max. advanced angle
32°CA
Ignition coil Above 200V Peak voltage
Pulse generator 150V
1-8
