13．Engine Overhaul Information
Tightening Torques
Item Quantities Thread Size (mm) Tightening Torque
(N.m)
Remark
Reverse Gear Sensor 1 M10*1.25 20
Spark Plug 1 M12*1.25 18
Water-temperature
Sensor
1 Rc1/8 8 Apply Thread Locker
Adjusting Nut,
Valve Clearance
4 M5 10
Nut, Primary Sheave 1 M20*1.5 115
Nut, Secondary
Sheave
1 M20*1.5 115
Ring Nut, Secondary
Sheave
1 M30*1 100
Nut, Front Drive Shaft 1 M14*1.5 97
Nut, Drive Bevel Gear 1 M22*1 145
Nut, Driven Bevel
Gear
1 M16*1.5 150
Fixing Nut, Clutch 1 M18*1.5 70 Counter Clockwise
Limit Nut, Drive Bevel
Gear Bearing
1 M60 110 Apply Thread Locker
Nut, Universal Joint
Yoke
1 M55 80
Counter Clockwise,
Apply Thread Locker
Bolt, Rocker Arm
Shaft
2 M14*1.25 28
Oil Drain Bolt 1 M12*1.5 30
Bolt, Overriding
Clutch
6 M8 26 Apply Thread Locker
Bolt, Magneto Stator 3 M6 10 Apply Thread Locker
Screw, CVT Plate 3 M6 10 Apply Thread Locker
Bolt, Oil Pipe 2 M14*1.5 18
Bolt, Oil Pump 3 M6 10
Bolt, Pressure
Release Valve
2 M6 10
Bolt, Drive Bevel
Gear Cover
4 M8 32
Bolt, Driven Bevel
Gear Cover
4 M8 25
Bolt, Gear Limit 1 M14×1.5 18
Bolt, Recoil Starter 1 M10×1.25 55
