13．Engine Overhaul Information
Tightening Torques
Item Quantiti
es
Thread Size
(mm)
Tightening Torque
(N.m)
Remark
14 M6 10 Bolt, Crankcase
3 M8 25
Bolt, Driven Sector Gear 1 M6 12
Bolt, Oil Filter 1 M20×1.5 63
Bolt, Oil Starter Motor 2 M6 10
Bolt, Cylinder Head 4 M10 38
Bolt, Cylinder Head 2 M6 10
1 M8 25
Bolt, Cylinder (Upper &
Lower)
4 M6 10
Bolt, Cylinder Head
Cover
12 M6 10
Bolt, Chain Tensioner 2 M6 10
Nut, Chain Tensioner 1 M8 8
Bolt, Fan Motor 3 M6 10
Bolt, Thermostat
Housing
2 M6 10
Bolt, Water Pump Cover 3 M6 6
Bolt, Water Pump 2 M6 10
Fixing Bolt, Timing
Chain
2 M6 15
Apply Thread Locker
M5 4.5-6
M6 8-12
Other Bolts
M8 18-25
13-11
