13．Engine Overhaul Information
Maintenance Tools
Measurement Tools
No. Description Specification Purpose
1 Vernier Caliper 0-150mm For measuring the length and thickness
2 Micrometer 0-25mm For measuring outer diameters of rocker arm, valve stem
and camshaft
3 Micrometer 25-50mm For measuring the max. lift of camshaft
4 Micrometer 75-100mm For measuring piston skirt
5 Cylinder Gauge For measuring cylinder bore diameter
6 Small Bore Gauge 10-34mm Fore measuring inner gauge of rocker arm, piston pin bore,
connecting rod small end bore
7 Dial Indicator 1/100 For measuring the play
8 Straightedge Gauge Plane measuring
9 Feeler Gauge Plane and valve clearance measuring
10 Fuel Level Gauge For measuring the carburetor fuel level
11 Thickness Gauge For measuring the clearance
12 Spring Balance For measuring the spring tension
13 Tachometer For measuring engine speed
14 Oil Pressure Gauge For measuring oil pressure
15 Compression Gauge &
Adapter
For measuring cylinder compression
16 Radiator Cap Tester For measuring radiator cap opening pressure
17 Ohmmeter For measuring resistance and voltage
18 Ammeter For measuring current/switches
19 Thermometer For measuring liquid temperature
20 Timing Light For checking the ignition timing
21 Torque Wrench For measuring the tightening torque
General-purpose and Auxiliary Tools
22 Alcohol Burner Heating up
23 Magnetic Stand For micrometer
24 Slab Auxiliary tool for measuring
25 V-block For measuring the play
26 Tweezer For installation of valve cotter
27 Circlip Pliers For removal and installation of circlips
28 Long Nose Pliers For removal and installation of retainers
29 Impact Driver For removal of cross-headed bolts
30 (-) Driver
31 (+) Driver
