13．Engine Overhaul Information
Special Tools
No. Description Specifications Purpose
1 Spark Plug Wrench Removal and installation of spark plug
2 Clutch Holder For removing/installing clutch carrier nuts
3 Oil Filter Wrench Removal and installation of oil filter cartridge
4 Piston Pin Puller For removal of piston pin
5 Flywheel Puller For removal of magneto rotor
6 Crankcase Separating Tool For separation of left and right crankcase
7 Crankshaft Remover For removal of crankshaft from left crankcase
8 Crankshaft Installation Set For installing crankshaft to left crankshaft
9 Valve Spring Compressor For removal and installation of valve spring
10 Valve Seat Cutter For valve-seating
11 Ring Nut Wrench Removal/installation of CVT secondary sheave
12 Sheave Holder Removal/installation of CVT secondary sheave
13 Sheave Spring Compressor Removal/installation of CVT secondary sheave
14 Couple Gear/Middle Shaft
Tool
Removal/installation of the coupling gear nut
15 Bearing Driver Set For installation of bearing and oil seal
16 Bearing Removing Tool Set For removal of bearing
17 Oil Seal Removing Tool For removal of oil seal
18 Universal Joint Holder For removal/installation of the universal joint yoke nut
13-13
