14. Checks & Adjustment
Inspection of Cooling System
Check radiator, reservoir tank and water hoses.
Leakage or Damage: → Replace
Check coolant level by observing the upper and the
lower limit on the reservoir tank.
If the level is below lower limit, fill coolant until the level
reaches the upper limit.
Replacing Coolant
z Remove radiator cap and re① servoir tank cap .②
z Place a pan below water pump, and drain coolant by
removing drain plug and water hose .③④
z Drain coolant from reservoir tank.
z Clean radiator with fresh water, if necessary.
z Connect water hose and tighten drain ④ bolt ③
securely.
z Fill the specified coolant into the radiator.
z Loosen bleed bolt on water pump, when coolant ⑤
flow from bleed bolt, tighten the bolt. Install radiator
cap ①securely after filling coolant.
z Start the engine and keep it running for several
minutes. After warm up and cooling down the
engine, open radiator cap and check coolant. Fill the
specified coolant until the level is between the upper
and lower lines on the reservoir tank.
Caution:
Repeat the above procedures several times and make
sure the radiator is filled with coolant and air is
discharged.
14-10
Check initially at 40 hours or 1000km, replace
coolant every 2 years.
Warning !
z Do not open radiator cap when engine is hot,
you may be injured by escaping hot liquid or
vapor.
z Engine coolant is harmful. If coolant splashes in
your eyes or clothes, thoroughly wash it away
with water and consult a doctor. If coolant is
swallowed, induce vomiting and get immediate
medical attention.
z Keep coolant away from reach of children
