14. Checks & Adjustment
z Install oil dip rod, start the engine and allow it to run
for several minutes at idling speed.
z Turn off the engine and wait for about 3 minutes,
and then check the oil level on the dipstick.
Replacing Oil Filter
z Remove relative parts ( see Replacing Engine Oil)
z Remove oil filter① with the special tool
z Install washer and drain bolt
z Install new oil filter with the special tool
z Fill engine oil (about 2000ml) and check (see
Replacing Engine Oil)
Tool: Oil Filter Wrench
Inspection of External Oil Pipe
Check external oil pipe for leakage or damage.
Leakage or Damage: → Replace
14-9
Caution:
The engine oil should be changed when the engine is
warm. If the oil filter should be replaced, replace engine
oil at the same time.
Engine Oil Capacity
When replacing oil: 1.9L
When replacing oil filer: 2.0 L
Engine overhaul:2.2 L
