15. Engine Removal, Inspection & Installation
Balancer Shaft
z Remove the parts as illustrated on the right. Check
each part for abnormal wear or damage.
Wear or damage: → Replace
① Balancer shaft gear
② Woodruff key
③ Balancer shaft
④ Balancer shaft sprocket
⑤ Washer
⑥ Bolt
Magneto Rotor
z Remove starter clutch nut;
15-46
