15. Engine Removal, Inspection & Installation
Connecting Rod
z Install connecting rod to left crankcase with special
tool;
Note:
z Do not hammer the conrod into crankcase with
plastic mallet;
z Use special tool to avoid affect of conrod precision
Tool: Conrod Installer
Balancer Shaft
z Install balancer shaft
Caution: Balancer shaft driven gear should be aligned to
the mark as illustrated.
Main Shaft, Counter Shaft
z Install main shaft and counter shaft.
15-54
