2. Vehicle Body, Muffler
Rear Left Protector
Remove:
--Bolt 1
--Bolt 2
--Rear left protector
Installation:
Reverse the removal procedure for installation.
Rear Right Protector
Repeat the above procedure of removal and
installation for rear right protector.
Bumper, Bumper Protector,
Remove:
--2 bolts from engine skid plate (front)
--Bolt 1
--Bolt 2
--Bolt 3
--Bolt 4
Remove bumper with bumper protector
Remove Bolt 5 and Bolt 6 for bumper and front rack
2-13
