2. Vehicle Body, Muffler
Front Right Inner Fender
Remove:
--Bolt 1
--Bolt 2
--Front right inner fender
Installation:
Reverse the removal procedure for installation.
Note: The clasp of front right inner fender
should hook water pipe when it is assembled.
Front Left Inner Fender
Remove:
--Bolt 1
--Bolt 2
--Front left inner fender
Installation:
Reverse the removal procedure for installation.
Front Left Protector
Remove:
Bolt 1
Pull backward and remove front left protector
Installation:
Reverse the removal procedure for installation.
Front Right Protector
Repeat the above procedure of removal and
installation for front right protector.
2-12
