2. Vehicle Body, Muffler
Disassembly
Note: Side skid plate (front), side skid plate (center),
side skid plate (rear) and double seat protection plate are
located at the bottom of vehicle.
The maintenance person should have to work under the
vehicle bottom when disassembling the above parts. For
safety purpose, make sure that the vehicle should be firmly
parked.
Engine Skid Plate (Front)
Remove:
--Bolt 1
--Bolt 2
--Bolt 3
--Bolt 4
--Engine skid plate (Front)
Installation:
Reverse the removal procedure for installation.
Engine Skid Plate (Center)
Remove:
--Bolt 5
--Bolt 6
Engine skid plate (center)
Installation:
Reverse the removal procedure of installation.
Double Seat Protection Plate
Remove:
--Bolt 7
--Bolt 8
--Double seat protection plate
Note: This part is not available for single seat vehicle.
Installation:
Reverse the removal procedure of installation.
Engine Skid Plate (Rear)
Remove:
--Bolt 9
--Bolt 10
Engine skid plate (rear)
Installation:
Reverse the removal procedure for installation.
