3. Checks & Adjustment
Checking the Throttle Lever
Check the free play of throttle lever
Free play: 3-5mm
Out of range: →Adjust
Loosen locknut of throttle cable
turn the regulator and adjust free play of throttle lever
After adjusting, tighten locknuts and install throttle cable sleeve
Replace with a new throttle cable if the specified free play could
not be acquired by adjusting the regulator or if there is still
stickiness with the throttle.
Adjusting the Speed Limiter
The speed limiter is to limit the opening of throttle
Check the maximum length of limiter screw thread
Maximum screw thread: a=12mm
Adjust with a cross driver.
Note:
For beginners, the speed limit should be fully tightened.
Drivers with certain skills may adjust
the throttle with speed limiter
Maximum length of screw thread is 12mm.
It is recommended to adjust the thread length to 3-5mm.
3-11
