162 CG Drives & Automation, 01-5326-01r5
Min Pre Alarm Response delay [4182]
When the load level without interruption is below the alarm
level longer than set “Min PreAlarm delay” time, a warning
is activated.
Communication information
Min Alarm [419]
Min Alarm Margin [4191]
With load type Basic, [415], used the Min Alarm Margin
sets the band under the “Normal Load [41B]”, menu that
does not generate an alarm. With load type “Load Curve
[415]”, used the Min Alarm Margin sets the band under the
“Load Curve [41C]”, that does not generate an alarm. The
Max Alarm Margin is a percentage of nominal motor
torque.
In case of Load Curve R, the margin is percentage of Load
curve torque at the actual speed.
Communication information
Min Alarm Response delay [4192]
When the load level without interruption is below the alarm
level longer than set “Min Alarm delay” time, an alarm is
activated.
Communication information
Autoset Alarm [41A]
The Autoset Alarm function can measure the nominal load
that is used as reference for the alarm levels. If the selected
“Load Type [415]” is Basic it copies the load the motor is
running with to the menu “Normal Load [41B]”. The
motor must run on the speed that generates the load that
needs to be recorded. If the selected “Load Type [415]” is
Load Curve it performs a test-run and populates the “Load
Curve [41C]” with the found load values.
Communication information
4182 MinPreAlDel
Default: 0.1 s
Range: 0-90 s
Modbus Instance no/DeviceNet no: 43332
Profibus slot/index 169/236
EtherCAT and CANopen index (hex) 4d04
Profinet IO index 19716
Fieldbus format Long, 1=0.1 s
Modbus format EInt
4191 MinAlarmMar
Default: 15%
Range: 0-400%
Modbus Instance no/DeviceNet no: 43329
Profibus slot/index 169/233
EtherCAT and CANopen index (hex) 4d01
Profinet IO index 19713
Fieldbus format Long, 1=1%
Modbus format EInt
4192 MinAlarmDel
Default: 0.1 s
Range: 0-90 s
Modbus Instance no/DeviceNet no: 43333
Profibus slot/index 169/237
EtherCAT and CANopen index (hex) 4d05
Profinet IO index 19717
Fieldbus format Long, 1=0.1 s
Modbus format EInt
WARNING!
When autoset does a test run the motor
and application/machine will ramp up to
maximum speed.
NOTE: The motor must be running for the Autoset
Alarm function to succeed. A not running motor
generates a “Failed!” message.
41A AutoSet Alrm
Default: No
No 0
Yes 1
Modbus Instance no/DeviceNet no: 43334
Profibus slot/index 169/238
EtherCAT and CANopen index (hex) 4d06
Profinet IO index 19718
Fieldbus format UInt
Modbus format UInt
